Description
The GSM-based overload detection and protection system is designed to monitor electrical loads in real time. If an overload condition is detected, the system automatically sends an SMS alert to a registered mobile number and triggers an alarm. Additionally, a relay is activated to cut off the power supply, preventing potential damage to electrical appliances and reducing the risk of fire or electrical hazards.
Working Principle:
-
Load Monitoring: A current sensor (ACS712) continuously measures the current flowing through the circuit.
-
Overload Detection: If the current exceeds a predefined threshold, the microcontroller (such as Arduino) detects an overload condition.
-
Alert Mechanism:
-
An alarm (buzzer) is activated to notify locally.
-
A GSM module (SIM900) sends an SMS to a registered mobile number, informing the user about the overload condition.
-
-
Supply Cut-Off: A relay is used to disconnect the load from the power source, preventing damage to the electrical system.
-
Manual or Automatic Reset: The system can be reset manually or automatically after detecting normal load conditions.
-
Advantages:
-
Prevents Electrical Hazards: Protects appliances and wiring from damage due to excessive current.
-
Remote Monitoring: SMS alerts enable real-time monitoring of load conditions from anywhere.
-
Automatic Load Disconnection: Reduces the risk of fire and short circuits by cutting off the supply in overload situations.
-
Cost-Effective: Uses readily available components, making it affordable and easy to implement.
-
Improved Safety: Alerts and automatic shutdown enhance overall electrical safety.
Product Video
Package Includes
- 1 X GSM-Based Overload Detection and Protection System
