170 Points Mini Breadboard

Description

Solderless Breadboard is a high-quality breadboard with power lanes and printed top face for easy prototyping.<br>A breadboard is used to make up temporary circuits for testing or to try out an idea. No soldering is required so it is easy to change connections and replace components.<br>It is Reusable for fast build a prototype of an electronic circuit – will accept transistors, diodes, LEDs, resistors, capacitors and virtually all types of components – No soldering required – Can modify or revise the circuits easily Fit for jumper wire of 0.8mm diameter – Standard 2.54mm hole spacing Adhesive sheet on the backside of the board – Multiple breadboards can be spliced together too.<br>

Features

• Perfect for Arduino shield prototyping and testing
• Plastic housing, metal contact clips
• Maximum Voltage(V) : 300
• Maximum Operating Current (A) : 3 – 5
• Allowed Wire Size (AWG) : 29 ~ 20
• Use: experimental, testing, robot
• Matching jumper, diameter 0.8mm
• Phosphor bronze nickel plated spring clips
• 170 tie points
• Accepts 20-29 AWG wire sizes.
• Adhesive-backed for permanent mounting.
• L X W X H (mm) = 48 X 35 X 9
• Weight (gm) : 14

Package Includes

• 1 x Transparent Solderless Breadboard
