12V 100 RPM Johnson Geared DC Motor

Description

A DC geared motor is a type of motor that runs on direct current (DC) electricity and is equipped with gears. These motors are commonly used in various devices and machines to produce rotational motion at a controlled speed and torque. The gears attached to the motor help to increase or decrease the speed and power output according to the needs of the application. DC geared motors are often found in things like electric vehicles, robots, and home appliances, where precise control over movement is required.

Johnson geared motor Specification

• • Operating Voltage (VDC) : 6 ~ 18
  • Nominal Voltage (V) : 12
  • Rated Base Motor RPM : 18000
  • Gear Material : Metal
  • Rated Speed (RPM) : 100
  • Stall Torque (N-cm) : 235
  • Rated Power (W) : 8
  • Load Current Max (mA) : 900
  • Shaft Diameter (mm) : 6
  • Shaft Length (mm) : 30
  • Gearbox Diameter (mm) : 37
  • Motor Diameter(mm) : 27
  • Motor Length (mm) : 64
  • Operating Temperature (°C): -30 to 60
  • Weight (g): 177

Package Included

• 1 x Johnson Geared Motor High Torque Motor
